The Nike Hercules was a solid fuel propelled two-stage surface-to-air missile, used by U.S. and NATO armed forces for high- and medium-altitude air defense. It could also be employed in a surface-to-surface role, and demonstrated its ability to hit other short-range missiles.
Hercules was developed as the successor to the earlier MIM-3 Nike Ajax, with the ability to attack high-flying supersonic targets. It was initially deployed starting in 1959 in new bases, but eventually took over some existing Ajax bases as well. Hercules remained in service far longer than Ajax, with the last units in Europe only being deactivated in 1988.
Development and Deployment
The Nike-Hercules system, a follow-up to the Nike Ajax missile, was developed during the Cold War to destroy enemy bombers and enemy bomber formations, as well as serve as an anti-ballistic missile system. Western Electric, Bell Laboratories, and Douglas Aircraft Company were chief contractors for the system. Nuclear-armed Nike Hercules missiles were deployed in the United States, Greece, Italy, Korea and Turkey, and with Belgian, Dutch, and U.S. forces in West Germany. Conventionally armed Nike Hercules missiles also served in the United States, Germany, Denmark, Japan, Norway, and Taiwan. The first deployments in Europe began in 1959 and the last nuclear-armed Nike Hercules missiles in Europe were deactivated in 1988. The Nike-Hercules missile systems sold to Japan (Nike J) were subsequently fitted with upgraded internal guidance systems, the original vacuum tube systems being replaced with transistorized ones.
Capabilities
The Nike Hercules could carry either a nuclear warhead or a conventional high explosive warhead (T-45 fragmentation type). Initially the nuclear-armed version carried the W-7 Mod 2E nuclear warhead, with yields of 2.5 or 28 kt. Beginning in FY 1961 the older warheads were replaced by W-31 Mod 0 warheads, with yields of 2 kt (Y1) or 30 kt (Y2). The last versions carried the W31 Mod 2 warhead, with yields of 2 or 20 kt. The missile was 41 feet 6 inches (12.65 m) long with a wingspan of 6 feet 2 inches (1.88 m). 145 missile batteries were deployed during the cold war. The missile had a range of about 77 miles (124 km).
